Preface : Now that all the preliminary work for your upcoming project is complete, including preparing an estimate budget, creating mood boards, acquiring a brief understanding of the construction costs, perceiving the need of architects; it is slowly time to get more realistic and take a more concrete step towards creating your dream project. While the beginning of construction is quite an anticipated level to achieve, there are a few more crucial ticks one needs to check out. The first one out of that checklist is understanding and getting a professional to prepare the correct plans and drawings. The pertinence of these drawings can be highly felt when the design is being actually built on site. Each detail, dimension and decisions taken will be a part of these plans and sections; that will eventually lead to its implementation. So fasten your seat belts, and read on to find out the various drawings required in the pre-construction phase for a smooth execution.
Source: https://www.houzz.com/photos/eclectic-living-room-library-ideas-phbr2-bp~t_718~s_2104~a_34-482
One of the most daunting experiences in life is to embark upon a construction project which is your dream home. But even if it is not a house, whether it is commercial building or merely renovation project, it can be equally terrifying and demands meticulous planning and preparation. Among the most important steps is to have an experienced and licensed architect, and then you must make sure that they have prepared all the necessary designs and drawings before construction starts. These documents are essential not only for the construction process but also for obtaining necessary permits, dealing with contractors, and ensuring your vision is realized just as you want. Do not worry about it as we are here with a comprehensive guide to what you need from your architect before the first brick is cemented.
Architectural Drawings
Chaukor Design Studio : Best Architect in Ghaziabad
Site Plan
Transform your vision into reality with a site plan that's more than a drawing—it's your design's first step to perfection, crafted by the best architect in Ghaziabad.
Source: https://www.home-designing.com/luxury-house-exterior-facade-design-inspiration-photos/luxury-modern-home-design
A drawing where you get the detailed layout of the entire plot of land where the construction will take place is called a site plan. It includes the building position and orientation, the boundary wall, the entrance gate, the landscaping elements, driveways, garden area and other outdoor features. This plan also shows how the building is placed in respect of the surrounding building and elements like trees, roads, waterbody etc.
Floor Plan
Unlock your dream home with impeccable floor plans and expert designs—trust the best architect in Ghaziabad to bring your vision to life before construction begins.
Source: https://www.houzz.co.uk/magazine/8-open-plan-layout-mistakes-and-how-to-avoid-them-stsetivw-vs~169339266
Floor plans are exactly what the name suggests. It is the most critical architectural drawing for any construction project. They offer a detailed measurement of each floor of the building, showing the layout of rooms, walls, doors, windows, and sometimes furniture too. Floor plans help you understand how space is allocated and how different areas of the building connect with one another.
Elevations
Elevations are the artist's brushstrokes in the architectural world, best architect in Ghaziabad detailing every nuance and ensuring no stone is left unturned before construction begins.
Source: https://www.archdaily.com/1015896/cleave-house-dada-partners
Elevations are drawings of the building that illustrate the exterior appearance of the building from each side. They include material details, finishes, roof slopes, window glazing and other architectural elements. Elevations are helpful in visualizing the final look of the building and for ensuring that the design obeys to local regulations.
Sections
Elevate your build with expert sections and pre-construction designs—brought to life by the best architect in Ghaziabad for unparalleled precision and style.
Source: https://illustrarch.com/articles/13971-10-successful-architectural-section-drawings-by-architects.html
One of the most crucial drawings an architect will provide. These are sectional views of the building that reveal the internal structure and different floor levels. These drawings depict the vertical space distribution, the staircases, lifts and the relationship between floors, ceilings, and the roof. Sections help in visualizing the building’s structural integrity.
Structural Drawings
Chaukor Design Studio : Best Architect in Ghaziabad
With the best architect in Ghaziabad by your side, structural drawings transform vision into precision, ensuring every beam and column aligns perfectly before construction begins.
Source: https://www.archdaily.com/965979/bspn-residence-10-space-architects/6104221cc954fd01655c7476-bspn-residence-10-space-architects-photo
Structural drawings are the backbone of any construction project. They explain all the minutes details of the framework that supports the building, ensuring that it is safe and stable.
Foundation Plan
Laying a solid foundation is the first step to brilliance—design your dream with the best architect in Ghaziabad and turn pre-construction plans into architectural perfection.
Source: https://www.home-designing.com/luxury-house-exterior-facade-design-inspiration-photos/white-rendered-house-exterior
The foundation plan consists of the type and size of the foundation, including details about footings, slabs, and basement details. This plan includes the structural details like rebars, cement mix, and other elements that make the foundation. This is very crucial for the building’s stability and for preventing issues like settling or shifting.
Framing Plan
In the dance between form and function, must-have framing plans choreograph the symphony of spaces, harmonizing aesthetics with structural integrity—crafted by the best architect in Ghaziabad.
Source: https://boty.archdaily.com/us/2024/candidates/159995/baan-tita-house-slash-yangnar-studio
A framing plan shows the beams, columns, floor joists and other structural elements that supports the building. It ensures that the building will be adequately supported and can withstand all the future loads and stresses.
Roof Plan
Roof plans aren't just a blueprint; they're the vision that the best architect in Ghaziabad uses to crown your project with design excellence before construction even begins.
Source: https://bigsee.eu/house-eb-shaping-monch-und-nonne-on-curved-roof-sudtirol/
The roof plan includes details about the design and structure of the roof. It shows the details of roof measurement, slopes, rafters, water drainage elements etc. It may also include overhead water storage details.
Mechanical, Electrical, and Plumbing (MEP) Drawings
Chaukor Design Studio : Best Architect in Ghaziabad
MEP drawings are essential for the installation of systems that make the building functional and comfortable.
Mechanical Plans
Crafted with meticulous detail, mechanical plans breathe life into raw ideas, best architect in Ghaziabad transforming them into the essential framework for impeccable design execution.
Source: https://www.home-designing.com/2015/03/modern-home-exteriors-with-stunning-outdoor-spaces
Mechanical plans showcase the HVAC systems which include the heating, ventilation, and air conditioning layout. This is the layout of ductwork, vents, and equipment which will make sure the climate control and air quality are maintained properly.
Electrical Plans
Bright ideas start with meticulous electrical plans; achieve stunning pre-construction designs with the guidance of the best architect in Ghaziabad.
Source: https://www.houzz.in/photos/eclectic-living-room-design-ideas-phbr1-bp~t_26341~s_26737
This is the layout of all electrical components, including wiring, outlets, switches, and lighting fixtures. They prevent issues like overloads or short circuits by ensuring the wiring layout and load distribution is as per norms.
Plumbing Plans
Plumbing plans are the backbone of seamless pre-construction design, ensuring every fixture finds its perfect spot—brought to life by the best architect in Ghaziabad.
Source: https://archello.com/project/house-345
Plumbing plans provide the water supply and drainage systems of a building. In this drawing you will find layout of pipes, fixtures, and appliances, ensuring efficient water flow and waste management. Plumbing plans also address issues like water pressure and temperature control
Interior Design Drawings
Chaukor Design Studio : Best Architect in Ghaziabad
Great design begins with detailed drawings—count on the best architect in Ghaziabad to ensure every interior detail is perfectly planned and executed.
Source: https://www.elledecor.com/design-decorate/g8942056/open-floor-plans/
Interior design drawings focus on the aesthetics and functionality of the building’s interior spaces.
Interior Elevations
Design excellence starts with interior elevations—trust the best architect in Ghaziabad to bring your construction drawings to life with unmatched precision.
Source: https://www.houzz.in/photos/modern-living-room-design-ideas-phbr1-bp~t_26341~s_26738
Interior elevations are drawings which illustrate the detailed views of interior walls, the placement of doors, windows, cabinetry, and fixtures. These drawings are helpful in visualizing and planning the interior décor. They may also include the material and finish details.
Furniture Layouts
Furniture layouts are the cornerstone of exceptional design, ensuring a harmonious flow from concept to construction—expertly handled by the best architect in Ghaziabad.
Source: https://upqode.com/interior-design-websites/
In this drawing you will be provided with the furniture placement inside the building. It will showcase how each piece of furniture fits inside a room.
Finish Plans
The art of construction lies in the details—Finish Plans by the best architect in Ghaziabad ensure your design's final touches are nothing short of extraordinary.
Source: https://effectmagazine.effetto.com/8-interior-designers-predict-their-top-interiors-trends-for-2024/
Finish plans consists of the materials and finishes for floors, walls, ceilings, and other surfaces. They maybe illustrated in color to provide a better understanding of paints, textures etc.
Final Thoughts
Wrapping up with final thoughts turns your design ideas into actionable construction drawings—let the best architect in Ghaziabad guide your project to perfection.
Source: https://www.houzz.com/photos/contemporary-exterior-home-ideas-phbr1-bp~t_736~s_2103
Undertaking a construction project is a extensive undertaking that involves careful planning and teamwork. The detailed drawings and designs prepared by your architect form the foundation of a successful project. They help you and guide you in every step until the final construction is done. By prioritizing preparation and leveraging your architect’s expertise, you can building a structure that will stand the test of time.
